Sealing bar length: 2 x 660 mm
Spacing between the bars: 650 mm
Lid height: 180/300 mm
Sealing bar height: 35, 55 or 75 mm (0-25 mm on request)
Bag cut: Cut-off perforation or cut-off device with rotation knife
Output: Up to 3 cycles/min
Matching shrinking technology: AT 8, AS 660
Sealing bar length: 2 x 800 mm
Spacing between the bars: 650 mm
Lid height: 200/300 mm
Sealing bar height: 35 or 55 mm
Bag cut: Cut-off perforation
Output: Up to 3 cycles/min
Matching shrinking technology: AT 8, AS 660
Sealing bar length: 2 x 1000 mm
Spacing between the bars: 550 mm
Lid height: 180 or 250 mm
Sealing bar height: 15, 35, 55, 75 mm or optional automatic height adjustment (0-80 mm)
Bag cut: Cut-off perforation or complete cut-off in the chamber with exhaust system in intergrated containers
Indexing/Split belt: Available as an option
Out put: Up to 3 cycles/min
Matching shrinking technology: AT 8, AS 660
Sealing bar length: 2 x 1000 mm
Spacing between the bars: 830 mm
Lid height: 200 or 300 mm
Sealing bar height: 15, 35, 55, 75 mm
Bag cut: Cut-off perforation or cut-off device with rotation knife
Indexing/Split belt: Available as an option
Perforance: Up to 3 cycles/min
Matching shrinking technology: AT 15, AS 860
Sealing bar length: 2 x 1100 mm
Spacing between the bars: 830 mm
Lid height: 200 or 300 mm
Sealing bar height: 45, 65, 85 mm
Bag cut: Cut-off perforation or complete cut-off in the chamber with exhaust system in intergrated containers
Indexing/Split belt: Available as an option
Perforance: Up to 3 cycles/min
Matching shrinking technology: AT 15, AS 860
Sealing bar length: 2 x 1300 mm
Spacing between the bars: 830 mm
Lid height: 230 or 300 mm
Sealing bar height: 45, 65, 85 mm or optional automatic height adjustment (25-90 mm)
Bag cut: Cut-off perforation or complete cut-off in the chamber with exhaust system in intergrated containers
Indexing/Split belt: Available as an option
Perforance: Up to 3 cycles/min
Matching shrinking technology: AT 15, AS 860
Sealing bar length: 2 x 100 mm
Spacing between the bars: 1070 mm
Lid height: 200 or 300 mm
Sealing bar height: 45, 65, 85 mm
Bag cut: Cut-off perforation or complete cut-off in the chamber with exhaust system in intergrated containers
Indexing/Split belt: Available as an option
Perforance: Up to 3 cycles/min
Matching shrinking technology: AS 860
Sealing bar length: 2 x 1600 mm
Spacing between the bars: 830 mm
Lid height: 230 or 300 mm
Sealing bar height: 45, 65, 85 mm
Bag cut: Cut-off perforation or complete cut-off in the chamber with exhaust system in intergrated containers
Indexing/Split belt: Available as an option
Perforance: Up to 3 cycles/min
Matching shrinking technology: AS 860
