GK 1600 B
Sealing bar length: 1 x 405 mm
Max. product length: 1600 mm
Max. product height: 150 mm
Sealing bar height: 45 or 65 mm adjustable via the display
Bag cut: Cut-off perforation
Output: Up to 3 cycles/min
Matching shrinking technology: AS 400, AS 660
