GK 870/ 880 B SERIES
Sealing bar length: 2 x 100 mm
Spacing between the bars: 1070 mm
Lid height: 200 or 300 mm
Sealing bar height: 45, 65, 85 mm
Bag cut: Cut-off perforation or complete cut-off in the chamber with exhaust system in intergrated containers
Indexing/Split belt: Available as an option
Perforance: Up to 3 cycles/min
Matching shrinking technology: AS 860
Related products
Energy: Electric
Thermal insulation: 80 mm
Spray units: 2 water curtains from above, 1 water jet from below, additional water nozzles on the sides
Max. throughput width: 860 mm
Max. throughput height: 300 mm
Basin volume: approx. 330 l
Belt speed: 0.1 – 0.4 m/sec.
Operating temperature: 2°C and 5°C (35°F and 41°F)
Suitable packaging machine: Vacuum belt machines from GK 602 B
Energy: Electric, steam, electric/steam combined
Thermal insulation: 80 mm
Spray units: 2 water curtains from above, 1 water jet from below, additional water nozzles on the sides
Max. throughput width: 860 mm
Max. throughput height: 300 mm
Basin volume: approx. 330 l
Belt speed: 0.1 – 0.4 m/sec.
Vapor exhaust system: integrated
Suitable packaging machine: Vacuum belt machines from GK 602 B
Energy: Electric, steam, electric/steam combined
Thermal insulation: 80 mm
Immersion platform length: 1040 mm
Max. throughput width: 860 mm
Max. throughput height: 300 mm
Basin volume: approx. 460 l
Immersion cycles: up to 7 cycles/minute
Vapor exhaust system: integrated
Suitable packaging machine: Vacuum belt machines up to GK 602 B
Energy: Electric
Thermal insulation: 80 mm
Immersion platform length: 1040 mm
Max. throughput width: 860 mm
Max. throughput height: 300 mm
Basin volume: approx. 460 l
Immersion cycles: Up to 7 cycles/minute
Operating temperature: 2°C and 5°C (35°F and 41°F)
Suitable packaging machine: Vacuum belt machines from GK 602 B
Top air nozzles: 2 sensor-controlled nozzles follow the contours of the product
Air nozzle bottom: 1 rigid nozzle at the bottom
Volume of side-channel compressor: 1400 m3/h
Throughput width: 860 mm
Max. throughput height: 300 mm
Belt speed: 0.04 – 0.12 m/sec.
Matching shrinking technology: All shrink tanks and shrink tunnels
Sealing bar length (soft vacuum): 1300 mm
Sealing bar length (hard vacuum): 1300 mm
Spacing between the bars: 830 mm
Lid height: 200/ 300 mm
Sealing bar height: 55 mm, other heights upon request
Bag cut: Cut-off perforation or cut-off device with rotation knife
Matching shrinking technology: AT 15, AS 860
Sealing bar length: 2 x 800 mm
Spacing between the bars: 650 mm
Lid height: 200/300 mm
Sealing bar height: 35 or 55 mm
Bag cut: Cut-off perforation
Output: Up to 3 cycles/min
Matching shrinking technology: AT 8, AS 660
