AT 8
Energy: Electric, steam, electric/steam combined
Thermal insulation: 80 mm
Immersion platform length: 860 mm
Max. throughput width: 660 mm
Max. throughput height: 280 mm
Basin volume: approx. 240 l
Immersion cycles: up to 7 cycles/minute
Vapor exhaust system: integrated
Suitable packaging machine: Vacuum belt machines up to GK 501 B
Related products
Sealing bar length: 2 x 660 mm
Spacing between the bars: 650 mm
Lid height: 180/300 mm
Sealing bar height: 35, 55 or 75 mm (0-25 mm on request)
Bag cut: Cut-off perforation or cut-off device with rotation knife
Output: Up to 3 cycles/min
Matching shrinking technology: AT 8, AS 660
Energy: Electric
Immersion platform length: 730 mm
Throughput width: 535 mm
Immersion depth: 250 mm
Basin volume: 140 l
Suitable packaging machine: All single-chamber and double chamber machines
Energy: Electric, steam, electric/steam combined
Thermal insulation: 80 mm
Spray units: 2 water curtains from above, 1 water jet from below
Max. throughput width: 660 mm
Max. throughput height: 300 mm
Basin volume: approx. 205 l
Belt speed: 0.1 – 0.4 m/sec.
Vapor exhaust system: integrated
Suitable packaging machine: Vacuum belt machines up to GK 501 B
Sealing bar length: 2 x 1000 mm
Spacing between the bars: 830 mm
Lid height: 200 or 300 mm
Sealing bar height: 15, 35, 55, 75 mm
Bag cut: Cut-off perforation or cut-off device with rotation knife
Indexing/Split belt: Available as an option
Perforance: Up to 3 cycles/min
Matching shrinking technology: AT 15, AS 860
Energy: Electric, steam, electric/steam combined
Thermal insulation: 80 mm
Spray units: 2 water curtains from above, 1 water jet from below, additional water nozzles on the sides
Max. throughput width: 860 mm
Max. throughput height: 300 mm
Basin volume: approx. 330 l
Belt speed: 0.1 – 0.4 m/sec.
Vapor exhaust system: integrated
Suitable packaging machine: Vacuum belt machines from GK 602 B
Energy: Electric, steam, electric/steam combined
Heat insulation: 80 mm
Spray units: 2 water curtains from above, 1 water jet from below
Throughput width: 400 mm
Max. throughput height: 280 mm
Basin volume: approx. 120 l
Belt speed: 0.1 – 0.4 m/sec.
Vapor exhaust system: integrated
Dryer: Including integrated dryer
Suitable packaging machine: Thermoforming machines, flow pack machines
Sealing bar length: 4 x 620 mm
Spacing between the bars: 520 mm
Max. product height: 230 mm
Lid: Stainless steel
Pump size: 63/ 100/ 160 m3/h
Matching shrinking technology: AT 6 / AT 7
