EASYBAGGER
Bag length: 250 – 1000 mm
Bag width: 200 – 600 mm
Type of bag: Taped bags
Number of bag pull-off units: Up to 6 different formats of vacuum bags for
parallel operation
Belt speed of the single-bag module: Variably adjustable, belt start and stop using
foot switch
Width of product conveyor belt of the single bag module: 100 mm
Related products
Sealing bar length: 2 x 1000 mm
Spacing between the bars: 830 mm
Lid height: 200 or 300 mm
Sealing bar height: 15, 35, 55, 75 mm
Bag cut: Cut-off perforation or cut-off device with rotation knife
Indexing/Split belt: Available as an option
Perforance: Up to 3 cycles/min
Matching shrinking technology: AT 15, AS 860
Energy: Electric, steam, electric/steam combined
Heat insulation: 80 mm
Spray units: 2 water curtains from above, 1 water jet from below
Throughput width: 400 mm
Max. throughput height: 280 mm
Basin volume: approx. 120 l
Belt speed: 0.1 – 0.4 m/sec.
Vapor exhaust system: integrated
Dryer: Including integrated dryer
Suitable packaging machine: Thermoforming machines, flow pack machines
Sealing bar length: 2 x 800 mm
Spacing between the bars: 650 mm
Lid height: 200/300 mm
Sealing bar height: 35 or 55 mm
Bag cut: Cut-off perforation
Output: Up to 3 cycles/min
Matching shrinking technology: AT 8, AS 660
Top air nozzles: 2 sensor-controlled nozzles follow the contours of the product
Air nozzle bottom: 1 rigid nozzle at the bottom
Volume of side-channel compressor: 1400 m3/h
Throughput width: 860 mm
Max. throughput height: 300 mm
Belt speed: 0.04 – 0.12 m/sec.
Matching shrinking technology: All shrink tanks and shrink tunnels
Energy: Electric
Immersion platform length: 570 mm
Throughput width: 400 mm
Immersion depth: 250 mm
Basin volume: 70 l
Suitable packaging machine: All single-chamber and double chamber machines
Sealing bar length: 2 x 1000 mm
Spacing between the bars: 550 mm
Lid height: 180 or 250 mm
Sealing bar height: 15, 35, 55, 75 mm or optional automatic height adjustment (0-80 mm)
Bag cut: Cut-off perforation or complete cut-off in the chamber with exhaust system in intergrated containers
Indexing/Split belt: Available as an option
Out put: Up to 3 cycles/min
Matching shrinking technology: AT 8, AS 660
Energy: Electric
Thermal insulation: 80 mm
Immersion platform length: 1040 mm
Max. throughput width: 860 mm
Max. throughput height: 300 mm
Basin volume: approx. 460 l
Immersion cycles: Up to 7 cycles/minute
Operating temperature: 2°C and 5°C (35°F and 41°F)
Suitable packaging machine: Vacuum belt machines from GK 602 B
Energy: Electric, steam, electric/steam combined
Thermal insulation: 80 mm
Spray units: 2 water curtains from above, 1 water jet from below
Max. throughput width: 660 mm
Max. throughput height: 300 mm
Basin volume: approx. 205 l
Belt speed: 0.1 – 0.4 m/sec.
Vapor exhaust system: integrated
Suitable packaging machine: Vacuum belt machines up to GK 501 B
