Film roll diameter: up to 300 mm in diameter
Max. film width: Outside cut = 410 mm, Inside cut =350 mm
Film transport: Electromotive, unwinding and rewinding of film by pneumatic mandrel
High-performance control: IPC10″ swivel-mounted touchscreen, different languages, 80 distinct recipes, USB port allows for easy data backup, Remote diagnostic capability
(optional)
Compressed air: min. 6 bar
Roll diameter of the film: up to 300 mm in diameter
Tray depth: up to 100 mm
Product overhang: up to 25 mm
Tray depth for skin: up to 40 mm
High-performance control: IPC 7″ Touchscreen
Cycle rate: 4 – 8 cycles / min
Application: MAP, Skin seal
Compressed air: min. 6 bar
Electrical voltage: 3x 400V N/PE, 50/60 HZ
Weight: 450 kg
Space required: 1.6 qm
